ANKERMANN WILDRABBIT Gaming PC Intel Core i9-13900KF Z790-F RTX 4080 16GB 32GB DDR5 RAM 2TB SSD 1000W be quiet! Win 11 Pro onBoard WIFI + Bluetooth
Article number:
4260561746342
In stock
Bulletpoints
- [ Item number EAN: 4260561746342 ] --- Intel CPU i9-13900KF 24 Cores 5.8GHz LGA1700 (BX8071513900KF) - ASUS ROG STRIX Z790-F GAMING WIFI (90MB1CP0-M0EAY0) - 32GB Corsair Vengeance 5.600Mhz (CMK32GX5M2B5600C36)
- Nvidia GeForce RTX 4080 16GB HDMI / DisplayPort - 1000W Be Quiet! PURE POWER 12 M (BN345) - be quiet! Dark Base 700 black window (BGW23) - onBoard WIFI + Bluetooth
- 2TB Samsung 990 PRO NVMe M.2 (MZ-V9P2T0BW)
- Windows 11 64Bit Professional installiert aktiviert DPK (Ready to Work - ohne Datenträger)
- Assembled, tested and checked - 2 years warranty
Intel Core i9-13900KF
Z790-F
RTX 4080 16GB
32GB Corsair Vengeance 5.600Mhz
2TB SSD
1000W be quiet!
Dark Base 700 (BGW23)
Windows 11 64Bit Prof.
onBoard WIFI + Bluetooth
System performance
Office
Multimedia
Gaming
Workstation/CAD
System performance
Office
Multimedia
Gaming
Workstation/CAD
Product information "ANKERMANN WILDRABBIT Gaming PC Intel Core i9-13900KF Z790-F RTX 4080 16GB 32GB DDR5 RAM 2TB SSD 1000W be quiet! Win 11 Pro onBoard WIFI + Bluetooth"
CPU (Processor) | Intel Core i9-13900KF, 8C+16c/32T, 3.00-5.80GHz (BX8071513900KF) |
Mainboard | ASUS ROG STRIX Z790-F GAMING WIFI (90MB1CP0-M0EAY0) |
Video Card (VGA Card) | Nvidia GeForce RTX 4080 16GB HDMI / DisplayPort |
System Memory (RAM) | 32GB Corsair Vengeance 5600MHz DDR5 (CMK32GX5M2B5600C36) |
SSD | 2TB Samsung 990 PRO NVMe M.2 (Read 7450MB/s - Write 6900MB/s) |
Power Supply Unit (PSU) | 1000W be quiet! PURE POWER 12 M (BN345) ATX 3.0 |
Case (Case) | be quiet! Dark Base 700 black window (BGW23) |
CPU Cooler (Cooler) | Corsair iCUE H150i RGB ELITE (CW-9060060-WW) |
Operating System (Ready to use installed) | Windows 11 64Bit Professional installed activated digital key (ready to work - without data media) |
Case Fan | 2X 140mm Default Case Fan |
W-LAN Unit internal | onBoard WIFI + Bluetooth |
be quiet! Dark Base 700 black window (BGW23)
Outstanding flexibility and silence
The be quiet! Dark Base 700 midi-tower case offers unrivaled flexibility with impeccable cooling and silence features. Numerous customization options for component and cable layout, illumination and cooling make every PC one of a kind.
- Motherboard tray and HDD slots with enhanced possibilities for individual requirements
- Two be quiet! SilentWings® 3 140mm PWM fans
- Effective airflow system with noise-dampening vents
- 4-step dual-rail fan controller is switchable between Silence and Performance modes
- Ready for radiators up to 360mm on top, front and back
- Install fans and radiators on a provided bracket before installing it as a complete unit
- Completely sound insulated with decoupled motherboard, PSU and drives
- PSU shroud, ingenious cable routing and HDD slot covers for a neat interior
- Fully windowed side panel from tinted and tempered glass
- Exterior LEDs with six switchable colors and motherboard control option
- Three-year manufacturer’s warranty
- German product conception, design and quality control
The be quiet! Dark Base 700 midi-tower case offers unrivaled flexibility with impeccable cooling and silence features. Numerous customization options for component and cable layout, illumination and cooling make every PC one of a kind.
- Motherboard tray and HDD slots with enhanced possibilities for individual requirements
- Two be quiet! SilentWings® 3 140mm PWM fans
- Effective airflow system with noise-dampening vents
- 4-step dual-rail fan controller is switchable between Silence and Performance modes
- Ready for radiators up to 360mm on top, front and back
- Install fans and radiators on a provided bracket before installing it as a complete unit
- Completely sound insulated with decoupled motherboard, PSU and drives
- PSU shroud, ingenious cable routing and HDD slot covers for a neat interior
- Fully windowed side panel from tinted and tempered glass
- Exterior LEDs with six switchable colors and motherboard control option
- Three-year manufacturer’s warranty
- German product conception, design and quality control
Design
Form factor | Midi-Tower |
Type | PC |
Material | Acrylonitrile butadiene styrene (ABS), Aluminium, Steel, Tempered glass |
Number of 3.5' bays | 7 |
Supported motherboard form factors | ATX,EATX,Micro-ATX,Mini-ITX |
Colour of product | Black |
Backplanes support | Y |
Fan connector | 4-pin |
Top cover | Y |
Illumination location | Front |
Side window | Y |
Illumination | Y |
Illumination colour | Multi |
Number of expansion slots | 9 |
Maximum CPU cooler height | 18 cm |
Maximum graphics card length | 43 cm |
Maximum PSU length | 28.5 cm |
Certification | CE, RoHS |
Power supply
Power supply location | Bottom |
Supported power supply form factors | ATX |
Ports & interfaces
USB 3.0 (3.1 Gen 1) Type-A ports quantity | 2 |
USB 3.1 (3.1 Gen 2) Type-C ports quantity | 1 |
Audio input | Y |
Audio output | Y |
Cooling
Front fans installed | 1x 140 mm |
Maximum front fans | 2 |
Front fans diameters supported | 120,140 mm |
Rear fans installed | 1x 140 mm |
Maximum top fans | 3 |
Top fans diameters supported | 120,140 mm |
Maximum bottom fans | 1 |
Bottom fans diameters supported | 120,140 mm |
Fan power consumption | 1.68 W |
Fan rated current | 0.5 A |
Maximum airflow | 77.57 cfm |
Noise level (high speed) | 28.1 dB |
Fan rated voltage | 12 V |
Liquid cooling capability | Y |
Front radiator fan sizes supported | 120,140,240,280,360 mm |
Rear radiator fan sizes supported | 120,140 mm |
Top radiator fan sizes supported | 120,240,360 mm |
Storage
Supported hard disk drive sizes | 2.5,3.5' |
Weight & dimensions
Width | 241 mm |
Depth | 544 mm |
Height | 519 mm |
Weight | 13.2 kg |
Packaging data
Package width | 325 mm |
Package depth | 580 mm |
Package height | 640 mm |
Package weight | 14.4 kg |
32GB Corsair Vengeance 5600MHz DDR5 (CMK32GX5M2B5600C36)
Corsair Vengeance CMK32GX5M2B5600C36, 32 GB, 2 x 16 GB, DDR5, 5600 MHz, 288-pin DIMM, Black
Features
Internal memory | 32 GB |
Memory layout (modules x size) | 2 x 16 GB |
Internal memory type | DDR5 |
Memory clock speed | 5600 MHz |
Component for | PC/Server |
Memory form factor | 288-pin DIMM |
CAS latency | 36 |
Memory channels | Dual-channel |
Memory voltage | 1.25 V |
Intel Extreme Memory Profile (XMP) | Y |
Intel Extreme Memory Profile (XMP) version | 3.0 |
SPD profile | Y |
SPD voltage | 1.1 V |
SPD latency | 40 |
SPD speed | 4800 MHz |
Product colour | Black |
Cooling type | Heatsink |
Backlight | N |
Compatible products | Intel 600 Series |
2TB Samsung 990 PRO NVMe M.2 (Read 7450MB/s - Write 6900MB/s)
Samsung 990 PRO, 2000 GB, M.2, 7450 MB/s
Features
SSD form factor | M.2 |
SSD capacity | 2000 GB |
Interface | PCI Express 4.0 |
Memory type | V-NAND MLC |
NVMe | Y |
NVMe version | 2.0 |
Component for | PC |
Hardware encryption | Y |
Security algorithms | 256-bit AES |
Read speed | 7450 MB/s |
Write speed | 6900 MB/s |
Random read (4KB) | 1400000 IOPS |
Random write (4KB) | 1550000 IOPS |
PCI Express interface data lanes | x4 |
DevSlp (device sleep) support | Y |
S.M.A.R.T. support | Y |
TRIM support | Y |
Mean time between failures (MTBF) | 1500000 h |
Protection features | Heat resistant |
Power
Operating voltage | 3.3 V |
Power consumption (average) | 5.5 W |
Power consumption (idle) | 0.055 W |
Operational conditions
Operating temperature (T-T) | 0 - 70 °C |
Maximum operating temperature | 70 °C |
Operating shock | 1500 G |
Weight & dimensions
Width | 80 mm |
Depth | 2.3 mm |
Height | 22 mm |
Weight | 9 g |
Packaging data
Package type | Box |
Intel Core i9-13900KF, 8C+16c/32T, 3.00-5.80GHz (BX8071513900KF)
Intel Core i9-13900KF, Intel® Core™ i9, LGA 1700, Intel, i9-13900KF, 64-bit, 13th gen Intel® Core™ i9
Processor
Processor manufacturer | Intel |
Processor family | Intel® Core? i9 |
Processor generation | 13th gen Intel® Core? i9 |
Processor model | i9-13900KF |
Processor cores | 24 |
Processor socket | LGA 1700 |
Box | Y |
Processor threads | 32 |
Processor operating modes | 64-bit |
Performance cores | 8 |
Efficient cores | 16 |
Processor boost frequency | 5.8 GHz |
Performance-core boost frequency | 5.4 GHz |
Performance-core base frequency | 3 GHz |
Efficient-core boost frequency | 4.3 GHz |
Efficient-core base frequency | 2.2 GHz |
Processor cache | 36 MB |
Processor cache type | Smart Cache |
Maximum turbo power | 253 W |
Processor base power | 125 W |
Stepping | B0 |
Maximum number of DMI lanes | 8 |
Processor codename | Raptor Lake |
Memory
Maximum internal memory supported by processor | 128 GB |
Memory types supported by processor | DDR4-SDRAM, DDR5-SDRAM |
Memory channels | Dual-channel |
Memory bandwidth (max) | 89.6 GB/s |
Graphics
On-board graphics card | N |
Discrete graphics card | N |
On-board graphics card model | Not available |
Discrete graphics card model | Not available |
Features
Thermal Monitoring Technologies | Y |
Idle States | Y |
Execute Disable Bit | Y |
Market segment | Desktop |
Use conditions | PC/Client/Tablet |
Maximum number of PCI Express lanes | 20 |
PCI Express slots version | 4.0, 5.0 |
PCI Express configurations | 1x16+1x4, 2x8+1x4 |
Supported instruction sets | AVX 2.0, SSE4.1, SSE4.2 |
Direct Media Interface (DMI) Revision | 4.0 |
Embedded options available | N |
Scalability | 1S |
CPU configuration (max) | 1 |
Harmonized System (HS) code | 8542310001 |
Export Control Classification Number (ECCN) | 5A992C |
Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
Processor special features
Intel® Speed Shift Technology | Y |
Intel® Hyper Threading Technology (Intel® HT Technology) | Y |
Enhanced Intel SpeedStep Technology | Y |
Intel® Turbo Boost Technology | 2.0 |
Intel® AES New Instructions (Intel® AES-NI) | Y |
Intel® Thermal Velocity Boost | Y |
Intel® Turbo Boost Max Technology 3.0 frequency | 5.7 GHz |
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 | Y |
Intel® Thermal Velocity Boost Frequency | 5.8 GHz |
Intel® Control-flow Enforcement Technology (CET) | Y |
Intel® Thread Director | Y |
Intel® Deep Learning Boost (Intel® DL Boost) | Y |
Intel® Boot Guard | Y |
Intel® Volume Management Device (VMD) | Y |
Intel® Standard Manageability (ISM) | Y |
Intel Turbo Boost Max Technology 3.0 | Y |
Mode-based Execute Control (MBE) | Y |
Intel VT-x with Extended Page Tables (EPT) | Y |
Intel® Secure Key | Y |
Intel® OS Guard | Y |
Intel 64 | Y |
Intel Virtualization Technology (VT-x) | Y |
Intel Virtualization Technology for Directed I/O (VT-d) | Y |
Operational conditions
Tjunction | 100 °C |
Technical details
Status | Launched |
Launch date | Q4'22 |
Other features
L2 cache | 32768 KB |
2 x 140mm Default Case Fan
Windows 11 64Bit Professional installed activated digital key (ready to work - without data media)
onBoard Sound
onBoard Sound incl. 5.1 or 7.1 look at Ports Layout PlanASUS ROG STRIX Z790-F GAMING WIFI (90MB1CP0-M0EAY0)
Beneath its dark heatsinks and brooding aesthetic, the ROG Strix Z790-F packs a power solution and overclocking features that push Intel® 13th Gen Core processors to new heights. Flush with advanced thermal management for quieter builds, along with support for DDR5, PCIe 5.0, and WiFi 6E, this well-equipped powerhouse delivers massive bandwidth for everything. DIY-FRIENDLY FEATURES PCIE® SLOT Q-RELEASE A physical button unlocks the first PCIe slot?s security latch with one press, greatly simplifying the process of detaching a PCIe card from the motherboard when it?s time to upgrade to a new GPU or other compatible device. M.2 Q-LATCH The innovative Q-Latch makes it easy to install or remove an SSD from an M.2 slot. The design employs a simple locking mechanism to secure the drive, eliminating the need for a traditional screw. CLEAR CMOS The Clear CMOS button quickly resets BIOS settings to factory default. It can also be used to reboot the PC if incorrect BIOS settings have been selected. BIOS FLASHBACK? BIOS FlashBack? is a safe and simple way to update BIOS. Just drop the (UEFI) BIOS file onto a FAT32-formatted USB stick, plug it into the USB BIOS FlashBack port, and press the button. Updates can even be performed without having memory or a CPU installed. START BUTTON This convenient button removes the need to manually jump hard-to-reach pins during testing and troubleshooting. Q-LED Four onboard LEDs indicate power status and identify problems with CPU, memory, graphics card, or boot device for quick diagnosis. ALL-ROUND PERFORMANCE Robust power delivery, speedy storage and memory, and comprehensive cooling elevate any build with the ROG Strix Z790-F at its center. AI OVERCLOCKING Tuning is now faster and smarter than ever before. ASUS AI Overclocking profiles the CPU and cooling to predict the optimal configuration and push the system to its limits. Predicted values can be engaged automatically or used as a launching ground for further experimentation. PCIE 5.0 The top PCIe 5.0 x16 SafeSlot is well-equipped for the increased size and bandwidth of next-gen graphics cards. Zippy storage options abound with four PCIe 4.0 M.2 slots, all featuring robust heatsinks to maximize performance. POWER ARCHITECTURE 16 + 1 power stages rated to 90A each deliver ample current in order to drive 13th and 12th Gen Intel® Core? Processors through any workload with ease. ALLOY CHOKES AND DURABLE CAPACITORS Hi-end chokes and durable capacitors are engineered to resist extreme temperatures, enabling performance that exceeds industry standards. DUAL PROCOOL II POWER CONNECTORS ProCool II connectors are precision-built to ensure flush contact with PSU power lines. A metal sheath improves heat dissipation and lowers electrical impedance. SIX-LAYER PCB A multi-layered printed circuit board design quickly dissipates heat around the voltage regulators to improve overall system stability and provide the CPU with more overclocking headroom. DDR5 DOMINATION ROG has a long legacy of flexing the fastest memory performance, and DDR5 is no outlier. Thanks to improved signal routing, now enthusiast-grade kits have been driven far beyond the 7 GT/s mark on the Strix Z790-F, and who knows how far future DIMMs can go? Seasoned veterans can test their mettle by tinkering with the extensive array of tuning options in the UEFI.? AEMP II ASUS Enhanced Memory Profile (AEMP) is an exclusive hardware and firmware solution to overclock generic memory modules. AEMP?s second version allows for automatic tuning of kits during system startup and leverages the PCB trace optimizations of the Strix Z790-F to push frequencies higher than ever before. AEMP II can even overclock mixed kits in a quad-DIMM arrangement, and the vast library of support now extends to nearly every DDR5 module that does not otherwise have XMP support. VRM HEATSINK ARRAY Covering the power solution are two thick heatsinks connected by a heatpipe, sharing cooling capacity across VRMs and providing ample surface area and mass to handle the power needs of high-performance Intel 13th Gen processors.? M.2 BACKPLATE? An integrated backplate helps ensure that high-performance drives can deliver peak performance, even when airflow is restricted. M.2 HEATSINKS Heatsinks cover every slot to help keep onboard NVME SSDs at optimal temperatures for consistent performance and reliability. CPU FAN HEADERS A dedicated PWM/DC fan header provides easy access to CPU coolers. AIO PUMP FAN HEADER A dedicated PWM/DC header connects self-contained water-cooling setups. 4-PIN FAN HEADERS Each header supports auto-detection of PWM or DC fans. LEADING CONNECTIVITY The ROG Strix Z790-F delivers next-gen connectivity for ultrafast data transfers and low-latency networking. Those perks are joined by an advanced audio solution that allows you to pick out the smallest cues and home in on your opponents. WIFI 6E Onboard WiFi 6E technology takes advantage of newly available spectrum in the 6 GHz band to provide up to seven 160 MHz channels for ultrafast throughput and better performance in dense wireless environments. * WiFi 6E availability and features are dependent on regulatory limitations and co-existence with 5 GHz WiFi 2.5G ETHERNET Low-latency gaming, speedy file transfers, and high-resolution video streaming are among the many perks of onboard Intel® 2.5 Gbps Ethernet. USB 3.2 GEN 2X2 The Strix Z790-F comes loaded with two USB 3.2 Gen 2x2 Type-C® connectors for speedy data transfers up to 20 Gbps. One is a port on the rear I/O; the other can be attached to the chassis front panel and it also features Power Delivery (PD) 3.0 technology to quickly charge devices up to 30W. SUPREMEFX ROG SupremeFX is a unique blend of hardware and software technologies that provide superior audio. The Strix Z790-F implementation features the ALC4080 codec for high-resolution playback up to 32-bit/384 kHz across all channels. Front-panel output is streamed through the integrated Savitech amplifier that can drive high-fidelity acoustics to a wide variety of speakers and headsets. PLAY IN STYLE Brooding aesthetics and Aura Sync RGB controls allow the ROG Strix Z790-F to effortlessly flex between blending in and showing off. UNDENIABLY ROG STRIX When the lights are out, the ROG Strix Z790-F blends into the shadows with its dark pcb and black metal heatinks. Activate the customizable RGB logo on the shroud, and the board makes a bold statment. Transparent layers and subtle brand-centric details add aesthetic depth and texture. Pair the Strix Z790-F with other products from the diverse ROG ecosystem to create a fully-customized gaming setup that reflects your personal style. OUTSHINE THE COMPETITION ROG Strix motherboards feature ASUS Aura technology, enabling full lighting control and a variety of presets for both onboard RGB LEDs and third-party accessories. Effects can be easily synced across compatible ROG graphics cards, monitors, keyboards, and mice to give your setup a unified look. COOLER COMPATIBILITY The ROG Strix Z790-F bears the same LGA 1700 socket as the Z690 models, so it is backward compatible with all coolers that supported the previous generation, including all AIO offerings from ASUS and ROG. THE ROG STRIX ECOSYSTEM AWAITS Level up your game with ROG Strix. Enjoy complementary aesthetics, control, and compatibility across AIO coolers, cases, peripherals, and much more. ROG offers more choices than any other brand. SOFTWARE UTILITIES A myriad of ROG-exclusive tools put advanced system tuning and configuration at your fingertips. AI COOLING II Balance the thermals and acoustics of any build with a single click. A proprietary ASUS algorithm slashes unnecessary noise while running a quick stress test, and then monitors CPU temperatures to dynamically adjust fans to optimal speeds. TWO-WAY AI NOISE CANCELATION This utility leverages a massive deep-learning database to reduce over 5 million types of background noise from incoming or outgoing audio, helping ensure crystal-clear communication in games or calls. AI NETWORKING GameFirst VI optimizes networking performance by allocating bandwidth in real time based on application usage scenarios and corresponding learning algorithms. The latest update includes dedicated support for GeForce NOW to ensure the lowest latency possible during intense game streaming sessions. The renowned ROG UEFI (BIOS) provides everything you need to configure, tweak, and tune your rig. It offers intelligently simplified options for newcomers to PC DIY, as well as more comprehensive features for seasoned veterans. MEMTEST86 For diagnostic convenience, MemTest86 has been pre-installed into the ROG UEFI. Run the test to pinpoint memory issues without the need to start up the OS or attach a USB drive. Memory test results are stored in the BIOS archives for later reference. Intuitive Graphical Fan Controls Fine-tune individual fans simply by dragging a curve with the mouse. Storage Information View SATA port details for easy device recognition. Clock Adjustment Click on the settings icon to quickly change time and date settings. The AI Suite 3 dashboard contains a set of intuitive controls that boost CPU performance while maintaining system stability. The TurboV Processing Unit (TPU) is an intelligent onboard micro-controller that provides an array of system-tuning features, including the ability to fine-tune voltages, monitor system stats and adjust overclocking parameters. The Digi+ voltage-regulator module (VRM) delivers real-time control over voltage droop, switching frequency, and power-efficiency settings, allowing you to fine-tune CPU voltage regulation for ultimate stability and performance. Modern processors feature per-core tuning, and the ASUS Turbo app makes use of this feature by letting you assign applications to specific processor cores, prioritizing computing power where it's needed most. Sonic Studio supports HRTF-based (head-related transfer function*) virtual surround for headsets, casting an immersive aural landscape that draws you deeper into the action. The intuitive Sonic Studio interface also offers a range of EQ options and one-click presets, allowing you to tailor acoustics to suit personal preferences or the characteristics of your headset. APP-SPECIFIC PROFILES Apply customized audio settings to different applications, so everything you do is perfectly tuned to the way you want to listen. ROG Strix Z790 motherboards are pre-loaded with the DTS® Sound Unbound? app that envelops you in audio as never before, conjuring whole new levels of immersion for extraordinary gaming and entertainment experiences. By leveraging Windows Sonic spatial technology, DTS Sound Unbound delivers audio in a virtual 3D space ? putting you right in the middle of the soundscape, where you can sense the location of every gunshot, footstep, and other sounds.* * DTS Sound Unbound requires in-game support. Check with game publishers for supported titles. STEREO SOUND Discrete left and right audio channels enable headphone or two-speaker setups. SURROUND SOUND Audio is split and served over multiple speaker channels ? e.g., 5.1 or 7.1 ? to create an enveloping experience on a single, logical plane. SPATIAL SOUND A virtual 360-degree soundscape immerses you in a realistic sonic experience. The ROG Strix Z790-F includes a sixty-day AIDA64 Extreme subscription, a tool that provides detailed information about hardware and software, as well as benchmarks to measure the performance of the entire system or individual components. AIDA64 Extreme includes a monitoring and diagnostics feature to detect and prevent hardware issues. All vital system sensors can be tracked in real time, allowing voltage readings, fan speeds, and temperature information to be displayed on the desktop or sent to dedicated displays or to the LCD panels of ROG AIO liquid coolers*. * Support available for ROG Ryujin II and later models. Armoury Crate is a software utility designed to give you centralized control of supported gaming products, making it easy to tune the look and feel of your system. From a single intuitive interface, Armoury Crate helps you customize RGB lighting and effects for compatible devices and synchronize them with Aura Sync to create a unified lighting scheme across your system. In addition, Armoury Crate?s Fan Xpert4 tool provides comprehensive control over fans, water pumps, and all-in-one (AIO) coolers. You can use Armoury Crate to download drivers, tools, and user manuals, and to register products. It also taps into a special news feed that connects you to the global ASUS gaming community. * Windows 10 or 11 required for full Aura Sync functionality within Armoury Crate. For Windows 8 and earlier versions, standalone Aura Sync software is available for free download from the product support site.?
Processor
Processor manufacturer | AMD |
Processor socket | LGA 1700 |
Compatible processor series | Intel® Celeron®, Intel® Core? i3, Intel® Core? i5, Intel® Core? i7, Intel® Core? i9, Intel® Pentium® Gold |
Supported processor sockets | LGA 1700 |
Memory
Supported memory types | DDR5-SDRAM |
Number of memory slots | 4 |
Memory slots type | DIMM |
Memory channels | Dual-channel |
Non-ECC | Y |
Supported memory clock speeds | 4800,5000,5200,5400,5600,5800,6000,6200,6400,6600,6800,7000,7200,7400,7600,7800 MHz |
Supported memory clock speed (max) | 7800 MHz |
Maximum internal memory | 128 GB |
Unbuffered memory | Y |
Storage controllers
Supported storage drive types | HDD & SSD |
Supported storage drive interfaces | M.2, SATA III |
RAID support | Y |
RAID levels | 0, 1, 5, 10 |
Graphics
Parallel processing technology support | Not supported |
Internal I/O
USB 2.0 connectors | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
Number of SATA III connectors | 4 |
Front panel audio connector | Y |
ATX Power connector (24-pin) | Y |
CPU fan connector | Y |
Number of chassis fan connectors | 5 |
EPS power connector (8-pin) | Y |
Thunderbolt headers | 1 |
12V power connector | Y |
RGB LED pin header | Y |
Rear panel I/O ports
USB 2.0 ports quantity | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
HDMI ports quantity | 1 |
HDMI version | 2.1 |
DisplayPorts quantity | 1 |
DisplayPort version | 1.4 |
Line-in | Y |
Headphone outputs | 1 |
Microphone in | Y |
S/PDIF out port | Y |
WiFi-AP antenna jack | 2 |
Network
Ethernet LAN | Y |
Ethernet interface type | 2.5 Gigabit Ethernet |
Wi-Fi | Y |
Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax) |
Bluetooth | Y |
Bluetooth version | 5.3 |
Features
Component for | PC |
Motherboard form factor | ATX |
Motherboard chipset family | Intel |
Motherboard chipset | Intel Z790 |
Audio chip | Realtek ALC4080 |
Audio output channels | 7.1 channels |
Power source type | ATX |
Windows operating systems supported | Windows 10, Windows 11 |
Expansion slots
PCI Express x1 (Gen 3.x) slots | 1 |
PCI Express x16 (Gen 4.x) slots | 2 |
PCI Express x16 (Gen 5.x) slots | 1 |
Number of M.2 (M) slots | 4 |
BIOS
BIOS type | UEFI AMI |
BIOS memory size | 256 Mbit |
Clear CMOS button | Y |
Packaging data
Package width | 368 mm |
Package depth | 293 mm |
Package height | 290 mm |
Package weight | 2.25 kg |
Weight & dimensions
Width | 305 mm |
Depth | 244 mm |
Packaging content
Cables included | SATA |
User guide | Y |
Drivers included | Y |
Other features
Back-to-BIOS button | Y |
Nvidia GeForce RTX 4080 16GB HDMI / DisplayPort
1000W be quiet! PURE POWER 12 M (BN345) ATX 3.0
Corsair iCUE H150i RGB ELITE (CW-9060060-WW)
Corsair iCUE H150i RGB ELITE, All-in-one liquid cooler, 12 cm, 1850 RPM, 19 dB, 35.8 dB, 65.57 cfm
Performance
Suitable location | Processor |
Type | All-in-one liquid cooler |
Fan diameter | 12 cm |
Supported processor sockets | LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1366 (Socket B), LGA 1700, LGA 2011 (Socket R), LGA 2066, Socket AM4, Socket AM5, Socket TR4, Socket sTRX4 |
Rotational speed (max) | 1850 RPM |
Noise level (low speed) | 19 dB |
Noise level (high speed) | 35.8 dB |
Minimum airflow (imperial) | 16.5 cfm |
Maximum airflow | 65.57 cfm |
Minimum air pressure | 0.15 mmH2O |
Maximum air pressure | 2.68 mmH2O |
Pulse-width modulation (PWM) support | Y |
Quantity per pack | 1 pc(s) |
Design
Product colour | Black |
Radiator material | Aluminum |
Base plate material | Copper |
Number of fans | 3 fan(s) |
Illumination LED | Y |
Number of LEDs | 16 |
Illumination colour | Multi |
Weight & dimensions
Radiator width | 39.7 cm |
Radiator depth | 12 cm |
Radiator height | 2.7 cm |
Tube length | 45 cm |
Weight | 1.1 kg |
Fan dimensions (W x D x H) | 120 x 120 x 25 mm |
Packaging content
Mounting kit | Y |
Screws included | Y |
onBoard WIFI + Bluetooth
onBoard LAN
Nicht warten - einfach finanzieren!
Bezahlen Sie schnell und unkompliziert in kleinen Monatsraten. Einfach Artikel auswählen, zur Kasse gehen
und mit der Zahlungsart "Finanzierung" die Ware bezahlen.
Weitere Details
Mögliche Laufzeiten:
Laufzeit in Monaten | Monatlich Rate | Effektiver Jahreszins | Gebundener jährl. Sollzinssatz | Gesambetrag |
6 | 6×28,95 EUR | 9,9 % | 9,48 % | 173,70 EUR |
10 | 12×17,64 EUR | 9,9 % | 9,48 % | 176,43 EUR |
12 | 12×14,82 EUR | 9,9 % | 9,48 % | 177,80 EUR |
18 | 18×10,11 EUR | 9,9 % | 9,48 % | 181,96 EUR |
Diese Angaben stellen zugleich das repräsentative Beispiel im Sinne des § 6a PangV dar. Vermittlung erfolgt ausschließlich für die Commerz Finanz GmbH, Schwanthalerstr. 31, 80336 München.
Mainboard connectors PC connectors on the back
(monitor/graphics card connectors are disabled if a VGA/GPU graphics card is installed additionally)
(monitor/graphics card connectors are disabled if a VGA/GPU graphics card is installed additionally)

LAN
1x


HDMI
1x


Display Port
1x

USB 2.0
2x

USB-A 3.0 Mainboard
4x

USB-A 3.1
2x

USB-C 3.1
2x

Audio Connectors Toslink
7.1x

Bluetooth
1x

W-LAN
1x
Graphics card / monitor connections

HDMI
1x

Display Port
3x
Front connections front side / top of the case

Audio In/Out
1x

USB-A 3.0
2x

USB-C 3.1
1x
Expansion cards - PCI / PCIe

W-LAN
1x
These connection options have been generated for you. In individual cases, deviations are possible.

NVIDIA Geforce RTX 4080
The NVIDIA Geforce RTX 4080 is one of the most powerful graphics cards on the market.
It features 16GB of GDDR6X memory, 9,728 CUDA cores, 48 RT compute units, 192 Tensor compute units, and supports HDMI 2.1, PCIe 4.0, and DisplayPort 1.4a.
In summary, the NVIDIA Geforce RTX 4080 offers fast ray tracing and AI-accelerated performance with DLSS 3, high energy efficiency with Ada Lovelace architecture, and broad support for various interfaces and features.
mehr anzeigen
weniger anzeigen

Windows 11
The latest operating system from Microsoft with the latest designs, drivers and support for the most modern hardware.
This machine has Windows 11 installed with all drivers.
mehr anzeigen
weniger anzeigen

32 GB RAM
The RAM is important for the computer's performance because it allows access to the data that is currently needed. The bigger and faster the RAM is, the better. We have installed 32 GB of RAM from a brand manufacturer in this computer.
mehr anzeigen
weniger anzeigen

Wlan / WiFi & Bluetooth
This device has WiFi / WLAN for wireless internet reception and Bluetooth functionality for wireless connection with peripherals. Be ready for any situation!
mehr anzeigen
weniger anzeigen
